- 203 DPI Resolution
- 300mm / Second Printing Speed
- 74mm Printing Width
- 80mm Ribon Outer Diameter
- Operating Temperature 5-45°C
- 1.000.000 Cutting Life
- 96 Languages Characters Support Including English
- Automatic Paper Cutter / Partial Cut / Full Cut
| MODEL | ZJ-8260 | |
|---|---|---|
| Print method | Drict, Thermal | |
| Print Speed | 300mm/Sec | |
| Effective Print Width | 72mm / 512 dots/line | |
| Characters per line | Font A: 42 columns, 180dpi Font B : 56 columns, 180dpi | |
| Internal memory | 64MB | |
| Motherboard | ow power consumption – automatic standby mode enables 30% less power use on average | |
| Paper loading | automatic |
| THERMAL PRINTER | ||
|---|---|---|
| Width: | 79.5 mm +/- 0.5 mm | |
| Thickness | 0.065 - 0.1mm | |
| Max. roll diameter | 83mm |
| CHARACTERS | ||
|---|---|---|
| Alphanumeric | 95 | |
| Extended graphic | 128 x 18 page | |
| International characters | 14 | |
| Barcodes | UPC - A, UPC-E, EAN-8, Code 39, Code 93, Code 128, ITF, Codabar, 2D PDF417, QR Code | |
| Emulation | ESC/POS compatible | |
| Drivers | Windows (XP, 2000, 2003, Vista, WEPOS) / Linux | |
| Sensor | end-of-roll, near end-of-roll, cover open | |
| Till output port(s) | 1 dual port (for 1 drawers) - RJ11 6-pin connector | |
| Interfaces | Triple interface RS232 Serial - USB & Ethernet dual (non-modifiable) | |
| Power supply | External 24V - 2.5A |
| PAPER CUTTER | ||
|---|---|---|
| Auto cutter | guillotine type Max. 30 cuts/minute | |
| Cut type | total or partial |
| OTHER FEATURES | ||
|---|---|---|
| MCBF | 35-50 million lines depending on type of use and paper thickness Printer head lifespan: 160km Paper cutter lifespan: Approx. 1.5 million cuts | |
| Operating temperature | -20 to +60°C | |
| Operating humidity | 10% to 90% (without condensation) | |
| Dimensions (D x W x H) | 177 x 142 x 149mm | |
| Weight | 1.9kg box | |
| Colour | Black |
ZJ-8260 Thermal Printer Frequently Asked Questions
The principle of the thermal printer is heated after a while, which becomes a dark (usually black or blue) film covered with a layer of pale material (usually paper) transparent film. Image Heating is created by the chemical reaction created in the film. This chemical reaction is not at a certain temperature. High temperatures can speed up the chemical reaction. When the temperature is below 60,, the film should go with a long as many years as even being dark; and when its temperature is 200 ℃, this reflection will be completed within a few microseconds. By selecting a thermal printer, it is heated to a predetermined position on the corresponding graphical thermal paper. The contact with the heat sensitive material is provided by a small electric heater with the print head. The heater forms a heating element arranged in square dots or strips guided by the printer logic control with the corresponding graphic on the thermal paper. Heating elements are controlled by logic circuit but also controlling feed can get graphic label or printing on all paper.
After downloading the zj-8260 driveri from our site, extract the file from RAR to the folder. Devices and printers. Add a printer. Add a local printer. Select the port. There is a floppy disk. Browse. We get the ZJPOS80.inf file inside the file we downloaded with the help of double click. OK. Further. The ileri.i. End. We right click on the Printer installed for the Ethernet setup and select the printer features. Ports. Add port. We choose standard TCP / IP Port. Further . We write the current IP number of the printer in the name and IP address of the printer. Further. Device type Press letter G. We see the Genetic Network Card. Further. End.
After downloading the zj-8260 driveri from our site, extract the file from RAR to the folder. Control Panel. Devices and printers. Add a printer. The printer I requested is not listed. Manual settings. We select the port we want. Further. Have Disk. Browse. We get the ZJPOS80.inf file inside the file we downloaded with the help of double click. OK. Further. End.
After downloading the zj-8260 driveri from our site, extract the file from RAR to the folder. Devices and printers. Add a printer. Add a local printer. Select the port. There is a floppy disk. Browse. We get the ZJPOS80.inf file inside the file we downloaded with the help of double click. OK. Further. The ileri.i. End. We right click on the Printer installed for the Ethernet setup and select the printer features. Ports. Add port. We choose standard TCP / IP Port. Further . We write the current IP number of the printer in the name and IP address of the printer. Further. Device type Press letter G. We see the Genetic Network Card. Further. End.
After downloading the zj-8260 driveri from our site, extract the file from RAR to the folder. Control Panel. Devices and printers. Add a printer. The printer I requested is not listed. Manual settings. We select the port we want. Further. Have Disk. Browse. We get the ZJPOS80.inf file inside the file we downloaded with the help of double click. OK. Further. End. We right click on the Printer installed for the Ethernet setup and select the printer features. Ports. Add port. We choose standard TCP / IP Port. Further . We write the current IP number of the printer in the name and IP address of the printer. Further. Device type Press letter G. We see the Genetic Network Card. Further. End.
After downloading the zj-8260 driveri from our site, extract the file from RAR to the folder. Devices and printers. Add a printer. Add a local printer. Select the port. There is a floppy disk. Browse. We get the ZJPOS80.inf file inside the file we downloaded with the help of double click. OK. Further. The ileri.i. End. We right click on the Printer installed for the Ethernet setup and select the printer features. Ports. Add port. We choose standard TCP / IP Port. Further . We write the current IP number of the printer in the name and IP address of the printer. Further. Device type Press letter G. We see the Genetic Network Card. Further. End.
After downloading the zj-8260 driveri from our site, extract the file from RAR to the folder. Control Panel. Devices and printers. Add a printer. The printer I requested is not listed. Manual settings. We select the port we want. Further. Have Disk. Browse. We get the ZJPOS80.inf file inside the file we downloaded with the help of double click. OK. Further. End. We right click on the Printer installed for the Ethernet setup and select the printer features. Ports. Add port. We choose standard TCP / IP Port. Further . We write the current IP number of the printer in the name and IP address of the printer. Further. Device type Press letter G. We see the Genetic Network Card. Further. End.
